A manual for officers of British Army in 1846 when there were more than 50 authorized descriptions of Ordnance.
Each carriage is illustrated with detail, scaled line drawings in both plan and elevation, and 18 tables of dimensions and weights.
Be sure to checkout the specifications tab to learn more specifics on what this book offers.
Specifications
- 7"X10"
- 64 Pages
- Soft cover
Contents:
- CARRIAGES
- 32, 24 and 18 Pounder Garrison Carriage Iron and Wood, Plan and Elevation
- 12, 24 Pr. Carronade Carriage, Bock and Trail Carriage and Carronade Slide, Plan and Elevation
- 13, 10 and 5 1/2 inch Land Service Mortar Bed, Plan and Elevation
- 8 inch Iron Howitzer (Millar), Plan, Elevation and Front View
- 10 inch Howitzer, Elevation
- 10 inch Howitzer, Plan
- Travelling Carriage, 8 inch Iron Howitzer Plan
- 18 Pounder, Elevation
- 18 Pounder, Plan
- 32 Pounder Howitzer, Elevation
- 32 Pounder Howitzer, Plan
- Elevation of the 24 Pr. and 12 Pr. Howitzer Carriage
- Plan of the 24 and 12 Pr. Howitzer Carriage
- 24 Pounder Siege Carriage, Plan
- 18 Pounder Bracket Carriage, Top Plan, Bottom plan, Side Elevation and Front View
- 12 Pounder Field Carriage, Plan
- Elevation of Gun Carriage for 9 Pr. And 6 Pr. Field Gun
- Plan of Gun Carriage for 9 Pr. and 6 Pr. Field Gun
- Elevation of Limber, 9 Pr. Field Gun
- Carriage for a light 3 Pounder Gun, Plan, Front Elevation
- Elevation of Ammunition Wagon
- Plan of Ammunition Wagon
- Mountain Artillery, as arranged for Mule Transport
- Elevation and Plan of a Light 3 Pounder (Mountain Service)
- 12, 6 Pr Rocket Carriage and 12 Pr. Rocket tube, Plan and Elevation
- Sling Wagon, with a 24 Pr. Gun and Garrison Carriage Slung, Plan and Elevation
- Sling Cart witha 24 Pr. Gun Slung, Plan and Elevation
- Devil Carriage with a 24 Pr. Gun and Garrison Carriage Slung, Plan and Elevation
- Forge Wagon, Elevation
- Forge Wagon, Plan
- CARRIAGE, DEPRESSION
- Depression Carriage for a 24 Pr. Iron Gun, Plan and Elevation
- Depression Carriage for a Light Brass 12 Pr. Gun, Plan and Elevation
- Iron Carriage for a 24 Pr. Howitzer on a Traversing Platform
- BOATS
- Plan of a Shifting Carronade Slide for a Launch, Plans and Elevations
- DEFENCE OF COASTS
- Dwarf Wooden Traversing Platform, Plan and Elevation
- Cast Iron Traversing Platform for Guns, Plan and Elevation
- Diagram of the central lines of the iron racers
- Plan and Elevation of the Iron Traversing Platform for Howitzers On Towers
- Platform furnished to the Circular Towers in England, Plan and Elevation
- Wooden Traversing Platform for Guns or Howitzers in Batteries, Plan and Elevation
